Other information:
CAUTION
Always be sure to clean the area
around any filler plug, drain
plug, or dipstick before checking
or draining any lubricant.
This is especially important in
dusty or sandy areas and when
the vehicle is used on unpaved
roads. Cleaning the plug and
dipstick areas will prevent d ...
Schematic Diagram
1.
Circuit diagram
2.
Connector terminal information
TerminalDescriptionCurrent (m/A) MAXMIN1Battery (+)12.5-2Battery12.5-3Parking brake switch20-4---5---6Electric parking brake switch signal 41057Electric parking brake switch signal 31058C-CAN LOW30209---10---11IGN20512 ...
